Testing Magnetic Fields with Gauss Meter
Testing Magnetic Fields with Gauss Meter

Precision Mill Gauss Meter (Magnetic Flux Index) GT-MB17

(Toys Testing)

  • Item NO.:

    GT-MB17
  • Lead Time:

    15days
  • Brand:

    GESTER
  • Payment:

    TT
Description


magnetic field gauss meter

应用程序:

Precision Mill Gauss Meter (Magnetic Flux Index) GT-MB17 Applicable for measuring magnetic induction intensity of all kinds of magnetic field, including DC magnetic field, AC magnetic field, etc. Portable, wide measuring range, easy operation and clear liquid crystal display.


Standards:

ISO 8124-1 section 5.32

GB 6675-2 section 5.27

EN-71-1 section 8.35,

ASTM F963 section 8.24.1



Feature:


  • Surface magnetic field of permanent magnetic material, DC motor, loudspeaker, magnetic separator, Permanent magnetic separators, etc.
  • Also can be used to measure the materials’ residual magnetic after mechanical processing, magnetic pole distribution, products’ residual field after demagnetization, and control electro with magnetic situation, measure the motor magnetic and leakage flux of electromagnetic field.




Key Specification:

Model

GT-MB17

Measuring range

0~200mT~2000mT

Axial

Longitudinal

Fundamental error

±2%

Resolving power

0.01mT,0.1公吨

Magnetic fieldmeasured

DC magneticfield(StaticMagneticField)

AC magneticfield(DynamicMagneticField)

Function

Peak-value-holding function

Gs(Gauss) / mT(Milli tesla) witched over automatically

Dc measurements with N/S polarity display

Button adjusted to zero position automatically

Battery capacity reminds constantly

Power supply

9V battery

Dimension

160mm x 88mm x 36mm

Weight

300g

Display

4 1/2 LCD

Display unit

mT/Gs (1mT=10Gs)

Standards

ISO 8124-1 section 5.32; GB 6675-2 section 5.27;

EN-71-1section 8.35; ASTM F963 section 8.24.1

Standard Accessories

Axial direction sensor -1pc
